QP-1150G • Size(L*W*H (mm)): 160*76.2*34.6 (above PCB) • Input voltage : 90~264VAC 47~63HZ • Output Voltage: 12V, 22V,24V,36V,48V Single Output • Efficiency: 89.5% min @230VAC input, Full load,ambient environment25℃ • Operating Temperature : ­-20°C~60°C 150W for Convection 80W for 80°C Ambient • ACTIVE PFC • Cooling by Base plate • Remote Sense • Adjustable Main Output QD-3161G • Size(L*W*H (mm)): 116*45.1*32.5 • Input voltage : 9~28VDC • Output Voltage: ATX Output • Efficiency: 85%@12VDC input,120W • Operating Temperature : 0°C~40°C 120W Output • Cooling by Base Plate • Selectable ON/OFF • Delay Control • OVP/SCP/UVP QD-3162G • Size(L*W*H (mm)): 116*45.1*32.5 • Input voltage : 18~28VDC • Output Voltage: ATX Output • Efficiency: 85%@24VDC input, 120W • Operating Temperature : 0°C~40°C 120W Output • Cooling by Base Plate • Selectable ON/OFF • Delay Control • OVP/SCP/UVP QD-3163G • Size(L*W*H (mm)): 116*45.1*32.5 • Input voltage : 12VDC • Output Voltage: ATX Output • Efficiency: 85%@12VDC input, 120W • Operating Temperature : 0°C~40°C 120W Output • Cooling by Base Plate • Selectable ON/OFF • Delay Control • OVP/SCP/UVP QL-AC30E • Size(L*W*H (mm)): 90*35*30 • Input voltage : AC90~264VAC • Output Voltage: DC 5V, 12V, 24V, 36V Single Output • Efficiency: 80% min 115-230,full load • Operating Temperature : 0°C~50°C • Full Range Input Voltage • Free air convection Cooling • EMI • Meet CE • Isolated • SCP QP-1250G • Size(L*W*H (mm)): 127*76.2*34.6 above PCB • Input voltage : 90~264V 47~63HZ • Output Voltage: 48V,52V,54V56V Single output • Efficiency: 84%min@110VAC Full Load • Operating Temperature : -20°C~50°C 250W for ForceAir 150W for convection • 3"X5" compact size • UL, TUV safety • Meet CE • ZVS Technology • ACTIVE PFC • Remote Sense • Adjustable Main Output • 300W Peak Output QD-5180G • Size(L*W*H (mm)): 150*50.8*30 • Input voltage : 12~28VDC • Output Voltage: ATX Output • Efficiency: 90%@12VDC input, Full load • Operating Temperature : 0°C~40°C 160W Output • Battery Manager • Selectable ON/OFF • Delay Control • OVP/SCP/UVP R3 • size: 60mm(L)*45mm(W)*20mm(H)   • 12V 80W output NO FAN • High Efficiency up to 90% • Wide input voltage 9~28VDC • Operation temperature：-20℃~70℃ • OVP,OTP protection QP-1204G • Size(L*W*H (mm)): 127*76.2*34.6 above PCB • Input voltage : 90~264VAC 47~63HZ • Output Voltage: 12V, 24V,36V,48V,52V,56V Single Output or Dual Output • Efficiency: 85% min @110VAC input, Full load • Operating Temperature : -­20°C~50°C 200W for Force Air 150W for Convection • 3"X5" compact size • UL, TUV safety • Meet CE • ZVS Technology • ACTIVE PFC • Remote Sense • Adjustable Main Output • 300W Peak Output
